BOT-313 Gas Boiler Heating Thermostat
We have two types for choice:
WIFI Control : BOT-313WIFI
Not Wifi Control:Hand control : BOT-313W
They are different thermostats. Please ensure which one you prefer before ordering!!!
- Power Supply: 200~240V 50~60Hz
- Current Load < = 3A(BOT-313WIFI: WIFI control),
- 2AA batteries(BOT-313W:Hand control)
- Power Consumption < 0.3W
- Set Temp. : 5~99 Celsius (factory default: 5~35 Celsius)
- Accuracy: 1/-1 Celsius
- Dimension: 86X86X40mm
WIFI control type : BOT-313WIFI
- Usage: BOT-313WIFI, wifi series thermostat could be used to control both gas boiler and thermal actuator. This thermostat will fit you if your house uses water heating system.
- Wifi controls: Control heating equipments via phone. You could set your house’s temperature anywhere you are.
- Green products & energy saving: Set in programmable mode, saving energy when you are not home.
Multi-language APP is coming soon……
Not Wifi Control : Hand Control type : BOT-313W
BOT-313W gas boiler thermostat is with LCD digital display screen. It is with 1.5V two sections of AA batteries. It is used to control boilers to start or stop working in order to adjust temperature. Thermostat detects room temperature, when actual room temperature is lower than your set temperature, thermostat controls boiler to start working. Then thermostat controls boiler to stop working when actual room temperature is higher than your set temperature.
BOT-313WIFI: WIFI control:86*86*40mm
BOT-313W: Not Wifi Control : Hand control: 85*85*26mm
Thermostat Wiring Diagram
BOT-313WIFI : WIFI control: Please connect L and N to 220 voltage power, 5 and 6 to your gas boiler. 1 and 2 are for thermal actuators, please do not connect them to your gas boiler.
Remarks: please read wiring diagram carefully before connecting. If you connect it wrongly, there will be a short circuit. Your gas boiler board will be damaged!!!
BOT-313W: Not WIFI Control : Hand control: For general gas boiler, it can be connected with NO and COM terminals! (NC terminal is for special gas boiler.)
Installation wires should be choosed to be 1.5-2.5 mm2 hard wire. Please rightly connect the wires strictly according to the connection diagram. Don’t make water, mud and other debris into the thermostat, otherwise it will damage the thermostat.
Attention: because of delivery limit, the order product is not equipped with battery.
BOT-313WIFI-WH is powered by AC230V and insterted into the wall.
BOT-313W.WH is powered by batteries and mounted on the wall.
